TECHNICAL SPECIFICATIONS:
Discharge sizes from 2-6 inches and horsepower range from 2-15 hp.
Utilizes 2-pole, 3600 rpm motors to achieve higher heads.
High pressure rated mechanical seals are isolated to provide superior motor protection.
Rugged cast iron construction.
Pressure relief ports and exclusive oil lifter extend mechanical seal life, eliminating premature wear and failure in high head operations.
Internal thermal motor protection.
Anti-wicking cable entrance.
Model Discharge Size(in.) Motor Output(HP) Diameter(in.) Height (in.) Max Solid Diameter(in.) Weight(lbs.) View Details
KTZ21.5 2 2 9 1/4 25 1/2 0.334 77 View Details
KTZ31.5 3 2 9 1/4 25 1/2 0.334 75 View Details
KTZ22.2 2 3 9 1/4 26 5/16 0.334 79 View Details
KTZ32.2 3 3 9 1/4 26 5/16 0.334 77 View Details
KTZ23.7 2 5 11 1/8 26 1/4 0.334 137 View Details
KTZ33.7 3 5 11 1/8 26 5/8 0.334 137 View Details
KTZ43.7 4 5 11 1/8 27 1/16 0.334 137 View Details
KTZ35.5 3 7.5 12 1/16 28 3/8 0.334 167 View Details
KTZ45.5 4 7.5 12 1/16 28 3/4 0.334 170 View Details
KTZ47.5 4 10 13 31 13/16 0.472 225 View Details
KTZ67.5 4 10 13 31 13/16 0.787 225 View Details
KTZ411 4 15 14 3/4 32 15/16 0.472 293 View Details
KTZ611 4 15 14 3/4 32 15/16 0.787 295 View Details
KTZE21.5 2 2 9 1/4 28 11/16 0.334 81 View Details
KTZE31.5 3 2 9 1/4 28 11/16 0.334 79 View Details
KTZE22.2 2 3 9 1/4 29 7/16 0.334 88 View Details
KTZE32.2 3 3 9 1/4 29 7/16 0.334 86 View Details
KTZE33.7 3 5 11 1/8 29 13/16 0.334 163 View Details
KTZE43.7 4 5 11 1/8 30 3/16 0.334 163 View Details
